美國ARC Audio BlackBird 12聲道DPS擴大機

ARC Audio BlackBird DSP 擴大機

96K/32bits大功率12聲道DPS擴大機

ARC Audio BlackBird DPS 特色

革命性進步：ARC Audio Blackbird 超越了 PS8-50 DSP 擴大機，在工程技術、內部設計、音質和性能方面取得了顯著提升。
OEM安裝友好：Blackbird 採用與 PS8-50 相同尺寸的設計，適合安裝在座椅下方或車輛儲物箱內。
強大功率：提供超過 1000 瓦的組合功率，8 個可橋接擴大機輸出通道，每通道功率在 75W 到 250W 之間（可根據配置）。
DSP控制RCA輸出：具備四個專用 DSP 控制的 RCA 輸出，每個輸出可達 8V，總共提供 12 個 Pro 系列 DSP 控制通道。
頂尖設計：適合最挑剔的音響愛好者，提供最廣泛和精細的調音功能，內建大量針對 OEM 整合的硬體選項。
iDATA Maestro 整合技術：支持即插即用 OEM 整合，與數千種車輛兼容，允許自定義音響系統，保留原廠功能。
高級DSP處理和調音：處理高達 96kHz、32 位元的音頻流，具備 444 個三分之一倍頻程或參數均衡頻段，每頻段可進行 1/10 dB 增量調節。
先進調音功能：包含全通濾波器、擱置濾波器、輸出訊號延遲、輸出相位、訊號混合器、輸出修剪控制及廣泛的分頻阻尼和混合斜率選擇。

ARC Audio Blackbird繼承並超越PS8-50，擁有超過1000瓦的綜合功率，易於OEM安裝。具備四個DSP控制RCA輸出和12個Pro-Series DSP控制通道，支持iDATA Maestro技術。頂尖DSP處理，處理96kHz/32位音頻，提供廣泛的調音功能，適合最挑剔的音響愛好者。

詳細規格介紹

8-Channels @ 4-Ohms (Ch 1-8)	75 Watts
8-Channels @ 2-Ohms (Ch 1 – 8)	125 Watts
4-Channel @ 4-Ohms (Ch 1-4 Bridged)	250 Watts
Amplifier Frequency Response	10Hz – 30kHz
Fuse	3 x 30 Amp
DSP	Built In
Processor Resolution	Fixed Point Native 32-Bits
Sample Rate	96kHz
Analog Inputs	8 ch. Differential in (RCA or Speaker Level)
Input Sensitivity	.5V – 32V RMS
Digital Inputs	TOSLink & Digital Coaxial (Requires D.O.C. Adapter)
Auto-sense Turn-On	Yes, Signal & DC (BTL) (Uses Ch 1/2 Inputs Only)
Outputs (RCA)	4-Channels Dedicated DSP Control)
Outputs Voltage (RCA)	Up to 8V
Input Impedance (rca)	10k ohms
Frequency Response	2Hz – 23.5kHz
S/N Ratio 1V 1:1	107.1dB
S/N 4V 1:1	108.dBdB
Operating Voltage	6V – 17.0V (Start Stop Compliance to 4.5V)
Output Equalization	444 Bands 1/3rd Octave (linkable) -or- 444 Bands variable Parametric EQ
Output Equalization Resolution	1/10th dB per step +20dB / -24dB
Output Signal Delay	Up to 30ms per channel in .01ms increments (Fixed Point Delay)
Input Signal Mixer	Yes – 10-Channels In (Including Digital) x 12-Channels Out (Including Up-Mixer Out)
Advanced Mixer (Output Signal Mixer / Required for 12-ch operation.)	Yes, When Selected
Easy-to-use Mixer Assistant	Yes
Crossovers	Phase Correct AP/HP/LP/BP all channels
Crossover Slopes	6dB, 12dB, 18dB, 24dB, 30dB, 36dB, 42dB, 48dB Slopes all bands all channels
Crossover Types	Butterworth, Linkwitz-Riley, Bessel, Variable Q, Chebyshev (all channels all bands)
Crossover selectable frequencies	10Hz – 20kHz in .01 Hz increments)
Output Signal up mixer	Yes
Input Signal Equalization	12-Bands Parametric (linkable) Per Channel
Input Equalization Resolution	1/10th dB per step +20dB / -24dB
Input Equalization All Pass Filters	Yes – Individual per input EQ band
Input Signal Delay	Yes – Up to 11.04ms per channel input
Presets	Up to 4-Presets
Hi-Res Bluetooth (Streaming Audio)	Yes – Requires ARC BTD (Sold Separately)
External Remote Level Control	Yes (ARC PSC or LR1) (Sold as an accessory, not included)
AXP WiFi control adapter card	Exclusive to the Pro Series DSP’s (Sold Separately)(COMING SOON)
Preset selection without controller use	Yes – Optional manual trigger switches +/- for up to 4 presets (Not Included)
Remote Turn-On Output Controls	Turn on Output (up to 40ms), Turn-on Hold (up to 40ms), Auto-sense hold time (up to 200ms)
Remote Turn-On Output On/Off lead timing control	Remote on/off adjustable up to 40ms each
Maestro AR Module interface capable	Yes – Requires Maestro T-Harness and data cable for connection
Expansion Capability (12-CH, 24-CH, 36-CH	Blackbirds can be ran in multiples with individual USB connections to a single PC with single operating software being used
Software Interface	64 bit Windows 8, Windows 8.1 or Windows 10
Dimensions	10.35”(L) x 6”(W) x 2”(H)
